Cummins brand power generation systems are the result of
integrated design and manufacturing intended to satisfy your requirements for rated
performance and reliable and efficient operation. For either standby or prime power,
Cummins produces a full line of diesel and spark-ignited generator sets, transfer switches,
paralleling switchgear, smart controls, sound attenuated housings, and installation
accessories. All products are designed and manufactured to work as a total,
integrated system. These power systems are backed by a worldwide network of
distributors and service branches plus a comprehensive warranty program. All systems
are subjected to prototype testing simulating rigorous real-world environments and meet
Cummins Total Quality System requirements. Cummins' manufacturing processes are ISO
9001 registered.
Extreme weather, construction activities, and countless other
unforeseen power complications can suddenly interrupt the electrical service you depend on
to continue your operations and activities. You can have complete peace of mind,
knowing that during a power outage your Cummins Standby System will activate to
provide the power necessary to run vital systems.
Fully automatic, the system detects an interruption of electrical
service and engages to power your essential systems. When utility power is restored,
the standby system shuts down, automatically resetting itself. The entire power
transfer cycle is fully automatic -- it is not necessary to be present for this system to
work!
Cummins Diesel Generator Sets
Cummins series 35 kW and larger diesel-fueled generator sets
offer a wide array of system features that can be tailored to your specific application,
whether standby, trailerized, or prime power. Examples include: multiple control
options, such as Detector™ control or the "smart" PowerCommand control,
various fuel tank configurations, housing options, voltage selections, cooling systems,
oversized alternators, and more.
If your requirements differ from those described here, click to request a custom quote.
Cummins Features
Compare these features with those offered on competitor's models.
Only Cummins has them all. Click here for more about the
Cummins brand and why it is worth spending a little more.
* Single-source design, manufacturing and testing of all set
components and
accessories by Cummins
Corporation and affiliated companies.
* Accepts 100% of nameplate kW rating in one step, in compliance
with
NFPA 110, Paragraph 5-13.2.6.
* Cummins heavy duty 4-cycle industrial engine with excellent
transient performance.
* Low reactance 2/3 pitch alternator with Class H insulation has
exceptional
short circuit capability, low waveform distortion with non-linear
loads and excellent
motor starting capabilities.
* Control Panel: vibration isolated start/stop control with Low Oil
Pressure and
High Coolant Temperature shutdowns.
* Electronic voltage regulator provides precise regulation,
underfrequency compensation, and fast recovery from transient load
changes.
* 105° F (40° C) ambient radiator cooling system.
* Skid base provides integral vibration isolation and supports the
alternator, radiator
and engine.
* Dual electro-deposition coating system provides high resistance
to scratching,
corrosion and paint fading.
* Low exhaust emissions - Certified to USEPA Mobile Off Highway
standards.
Specifications
Remember when selecting a diesel generator avoid extreme
oversizing. For proper performance you need to be able to achieve more than 30% of
full load rating on a regular basis.
Comprehensive warranty through fifth year is included as standard
on this genset when you purchase it from NoOutage.com. Quiet Site II housings, Detector 12 control, and smaller fuel
tanks are options available at different costs which can be selected using drop-down
menus below. If you require other options listed in the thumbnail image at the top
of this page describe them in the comments on checkout screen and we will show the adder
in your e-mail order acknowledgment for your approval.
Customers who purchased this product also ordered:
(click underlined words to see product pages)
Automatic transfer switch ZTX20RM4,
RSZ200-N1,
RSZ200-N3R or RST200/176.
Item Number: 35DGBB
Your Price: $13,858.00
Shipping Weight: 2273 lbs.
This item is shipped direct to you from the factory with free freight. It
normally goes out in 4 weeks. If you require shorter lead time, contact us for lead
time and shipping charges to ship from Maryland.
