400W Wind Generator
Land Version
AIR-X Wind Module Introducing the latest evolution in small wind turbines. The AIR-X builds upon what made AIR the world's #1 selling small wind turbine with new technology previously found only in today's state-of-the-art mega-watt-class wind turbines.
All of these features are primarily found within the body of the turbine. The new microprocessor based speed control results in increased performance, improved battery charging capability and the reduction of “flutter” noise from the machine. The controller allows for peak-power tracking of the wind by optimizing the alternator's output on all points of the cubic curve and then efficiently delivers the energy to the battery. The turbine’s smart controller allows it to actually control blade rotation speed thus eliminating the buzzing noise commonly found with the AIR 403 and 303 in high winds. Furthermore, a new series of carbon-reinforced blades with a modified pitch angle further increases power production.
The new electronics are a considerable improvement over the AIR 403 controller that consists of diode-rectification and a simple off/off voltage switch.
Much Lower Noise: Previous AIR wind modules relied on their aero-elastic blade design for protection in high winds, causing loud flutter noise in winds above 35 mph (16 m/s). AIR-X’s circuit monitors the wind speed and electronically slows the blades as it reaches its rated output preventing it from going into flutter. This results in a much quieter wind turbine. In high winds, the AIR-X will continue to produce power at a reduced level until the wind decreases, at which point maximum output will resume. The Benefit: Quieter and neighbor friendly operation.
Improved battery charging: Previous AIR designs required 300-400 amp hour battery banks so the trickle charge of the wind turbine could be adequately absorbed. The AIR-X’s charge controller periodically stops charging, reads the battery voltage, compares it to the voltage setting and if the battery is charged, it completely shuts off all current going to the battery. This function is performed within a few milliseconds. The closer the battery is to reaching its full state of charge, the more often the AIR-X’s circuit repeats this action. This means any size battery bank from 25 to 25,000 amp hours or higher can be charged safely. When the battery has reached its charged state, the AIR-X will slow to an almost complete stop. Only when the battery has dropped below its voltage set point will it startup and resume charging. The Benefit: Extended battery life, no overcharging.
DC cable length and voltage drop must be evaluated carefully when laying out system. Click here for our simple voltage drop calculator.
click to enlarge
Lower stress design: AIR-X limits power on the input side of the electronics by controlling the torque from the blades. The power no longer has to be dissipated by the electronics resulting in lower stress on the circuit, bearings and other materials. Furthermore, stress on wind turbines occurs primarily in high winds. Under these conditions, the electronic stall design reduces the blade speed to 600 rpm, thereby significantly reducing turbine and tower loading while still producing power. The Benefit: Greater confidence in turbine operation in high wind conditions without manually operating the stop switch. Note: A manual stop switch control is an available option for the AIR-X.
Design changes are primarily found within the body of the turbine:
|
|
|
|
Features
|
|
|
|
|
|
|
|
|
|
Applications
|
|
|
|
|
Specifications
Wind Generator Specifications |
|
| Rated Power Output | 400 watts at 28 mph |
| Output Voltage(s) | 12 or 24 Volts (48 volt version not yet available) (not field selectable, specify when ordering) |
| Rotor & Blade Configuration | 3.75 ft diameter rotor, 3 blades carbon-fiber reinforced |
| Standard Mounting | 2 inch schedule 40 pipe (1-1/2 inch schedule 40 for last 5 ft) |
| Tower Top Weight | less than 13 lbs |
| warranty | 3 years |
Customers who purchased this product also ordered:
(click underlined words to see product pages)
Manufacturer recommended lightning arrester LA-302-DC
Stop switch AIR-SW
Tower kits TOW-27-A or TOW-45-A or roof mount kit TOW-RMS
Tower-top junction box UPTOWER-JB
Augers TOW-AUG-36, TOW-AUG-48
Spare blade set AIR-BLADES
Item Number: AIRX
Price: $745
Price last updated 3/13/2009
Shipping Weight: 17 lbs. - dimensions 27x15x9 inches
This item normally ships in approximately 1 week or less.
